Unique nature of Karelia.
Types of modular ferro-concrete designs and technologists, their installation
1. Trellised farm.
2. Schemes of a frame and panel and beskarkasno-panel building.
3. Modular covers.
4. Schemes of a frame and panel and beskarkasno-panel building.
5. Construction of buildings from volume blocks with the help derezhabl.
The first largest constructions from monolithic reinforced concrete in the USSR
1. Long cylindrical covers. Zaporozhye, 1931.
2. Planetarium dome in diameter of 28 m in Moscow, 1929.
3. Theater dome in diameter of 55,5 m in Novosibirsk, 1934.
4. The station in Kiev, 1933.
5. Elevator. Kiev, 1953.
6. The bridge flight of 252 m in Zaporozhye, 1955.
Ladoga Canal
Ladoga Canal. Canalis Ladogenis nova Delineatio secundum exemplar Petropolitanum aeri incidit Matthaeus Seutter, Sac. Caes. Maj. Georg. Aug.V. Cum Priv.Sumi Vicariat in part Rheni, Franc. et Seuv. juris. (Augsburg, 1740-1750s). Scale approximately 1:150 000. Focused on the north-west.
Monastic complexes of Russia. Kirillo-Belozersky monastery (The Vologda area). XV\XVI centuries.
Church buildings: 1, 2, 3, 4, 5, 6, 14, 17, 25, 29 Fighting towers: 18, 22, 23, 34, 35, 36, 37, 38, 39, 40 Economic constructions: 7, 30 — refectory chambers; 9 — povarny; 11 — a merezhenny tower; 12 — a cooking tower; 13 — a grain tower; 14 — water gate; 19 —…
DetailsNorthern log hut in Russia XVII (according to D. Mileev).
1, 2 — living rooms; 3 — rooms for cattle (in 1 floor) N of a room for fodder and stock (in the 2nd floor).
“Reserved” zones in Moscow to the pogeneralny plan of 1970-1975.
1. China-town.
2. Kropotkinskaya Street.
3. Arbat.
4. Herzen Street.
5. Petrovka Street – Kuznetsky Bridge.
6. Street of Kirov.
7. Hmelnitskogo-Chernyshevskogo Street.
8. Zayauzye.
9. Zamoskvorechye.
Gorkogo Street in Moscow, expanded according to the project of 1935 I 18 meters (Tverskaya) to 42 meters. Project of architect A.Mordvinova.
A. – Street plan.
B. – the Street between Marx Avenue and the Moscow Council area.
The prospectus of Kalinin in Moscow.
Moscow at night. Business buildings “sleep”, but there live shops, clubs, cars rush, light – white, orange, green, red sparkles.
Change of an image of a house on an extent 50-x-70-x.
A. – Houses in the Southwest of Moscow, the 50th years.
B. – Houses on Leninsky Avenue, the 60-70th years.
С. – the House on Pushkin Square, the 40th years.
Novgorod. Architectural drawing. V.Shchuko, 1903. Pencil, water color.
Lines and own shadows as means of identification of the tectonic beginning in the image of architectural objects.
